Product Overview
The Rusco/Vu-Flow NT100-100P is a 1 in. PVC spin-down filter that captures sand, grit, and other visible sediment before it reaches downstream irrigation, plumbing, or water-treatment equipment. Water passes through a reusable 100-mesh polyester element while collected material settles in the clear service area for flushing. This makes the filter useful as an accessible first stage where the water source carries particles that could clog valves, emitters, screens, or additional filters.
The T-style body supports flow from 1 to 25 GPM and has a maximum pressure rating of 150 PSI. The element can be flushed and removed for cleaning, reducing the need to discard a cartridge at every service. Confirm particle size, flow, pressure, port style, and installation clearance before selection.
Key Features:
- 1 in. PVC spin-down filter
- 100-mesh polyester element
- Reusable and flushable design
- 1-25 GPM flow capacity
- 150 PSI maximum pressure
Common Uses:
- Well-water sediment pre-filtration
- Irrigation systems
- Protection for valves and downstream filters
- Sand and grit reduction
Technical Specifications:
- Port Size: 1 in. slip
- Mesh: 100
- Element: Polyester
- Flow: 1-25 GPM
- Maximum Pressure: 150 PSI
- Overall Size: 11-3/8 in. L x 5 in. W
Installation and Maintenance Notes:
Install with adequate service clearance and in the correct flow direction. Flush or clean the element as sediment accumulates.
FAQ:
Can the filter element be reused?
Yes. It can be flushed and removed for cleaning.
Does 100 mesh remove dissolved contaminants?
No. It is intended for suspended sediment of a compatible particle size.
