Rain Bird LCRBY200D 2-Inch NPT Large-Capacity Disc Filter

Rain Bird LCRBY200D 2-Inch NPT Large-Capacity Disc Filter

Brand: Rain Bird | SKU: LCRBY200D

Product Overview

LCRBY200D is a large-capacity disc filter for larger residential, commercial and municipal drip zones. Its removable disc stack provides filtration at a nominal 2-inch NPT connection. This is a filter rather than a pressure regulator or electric control valve, so plan those functions separately when the zone requires them.

Key Features

• 120-mesh / 130-micron disc filtration.
• Maximum recommended flow of 110 GPM for the 2-inch model.
• Disc stack can be removed and decompressed for cleaning.
• Thermoplastic housing with a polypropylene disc assembly.

Common Uses

• Filtration downstream of a control valve or shutoff point on a larger drip zone.
• Layouts where a serviceable disc element suits the water source and emitter filtration requirement.

Technical Specifications

• Model: LCRBY200D; manufacturer part X14607.
• Connections: nominal 2-inch NPT.
• Filter element: polypropylene discs, 120 mesh / 130 micron.
• Maximum recommended flow: 110 GPM.
• Disc filtering surface: 81 square inches / 525 square centimeters.
• Maximum pressure: 116 psi / 8 bar.
• Maximum water temperature: 140°F / 60°C.
• Body and cover: high-impact thermoplastic.
• No pressure-regulating or automatic valve function.
• Install after a valve or shutoff point; do not leave the filter under constant pressure.

Dimensions

The manufacturer’s 2-inch housing table lists H 9.76 inches, W 10.63 inches and D 5.67 inches. These are housing dimensions, not the required valve-box size or cartridge-removal clearance. The pipe connections are nominal 2-inch NPT.

Compatibility & Installation Notes

Match the 2-inch NPT connections, water quality, zone flow and downstream emitter filtration requirement. Install after a control valve or shutoff point where the filter will not remain under constant pressure; add a separate compatible regulator if the drip layout needs pressure reduction. The manufacturer’s 2-inch valve-box installation drawing shows the cartridge housing facing downward at 45 degrees, with enough room to remove the element for maintenance; valve-box extensions may be needed. Shut off the water and relieve pressure before opening the cover. The resource provided for installation is this model-specific drawing, so follow the applicable system instructions for the complete assembly.

Over the years, a select few products have risen above the rest with their unparalleled performance. We’re thrilled to share these gems with you. Whenever you spot the “From the Frog” badge, rest assured it’s more than just a mark of quality—it’s a symbol of our dedication and careful consideration in choosing the best for you.

Frequently Asked Questions

Does LCRBY200D regulate pressure?

No. It provides disc filtration; use a separate compatible regulator if the irrigation layout requires pressure reduction.

What is the filtration level and maximum flow?

The 2-inch LCRBY200D uses 120-mesh / 130-micron discs and has a maximum recommended flow of 110 GPM.

Can it stay on a constantly pressurized mainline?

No. Rain Bird specifies installation after a valve or shutoff point where the filter will not be under constant pressure.
