Rain Bird ESPLXMSM12 12-Station Expansion Module

Rain Bird ESPLXMSM12 12-Station Expansion Module

Brand: Rain Bird | SKU: ESPLXMSM12

Product Overview

Add twelve wired irrigation stations to a compatible Rain Bird ESP-LX controller with ESPLXMSM12. The plug-in module supports expansion into an available station-module slot or replacement of an existing 12-station module. Check the controller model and remaining capacity before ordering.

Key Features

• Provides twelve station outputs in one expansion module.
• Screw terminals secure the station wiring.
• Hot-swappable design allows module installation without powering down a compatible controller.
• Supports legacy LXME/LXMEF and LX Basic systems as well as LXME2/PRO installations.

Common Uses

• Adding separately controlled irrigation zones to a compatible modular controller.
• Replacing an existing 12-station module.
• Retaining 12-station capacity during an LXME-to-LXME2 upgrade.

Technical Specifications

• Model: ESPLXMSM12 / ESP-LXM-SM12
• Station outputs: 12 per module
• Compatible families: ESP-LXME, ESP-LXMEF, ESP-LX Basic, ESP-LXME2 and ESP-LXME2 PRO
• Connection type: screw-terminal station wiring
• Installation: plug-in station module; hot-swappable in compatible controllers
• LXME2/PRO system capacity: 12–48 stations using up to four 12-station modules
• Application: station expansion or replacement; controller purchased separately

Compatibility & Installation Notes

Confirm the controller family and an available station-module slot before purchase. Seat the module according to the controller manual, then review and accept the detected module configuration and apply the correct station-number labels. Wire stations according to that numbering rather than assuming the terminal layout matches an older module.

Rain Bird’s screw-terminal bulletin confirms interchangeability with older swing-arm station modules. LXME2/PRO accepts 12-station modules; older 4- and 8-station modules must be replaced when making that controller upgrade. Station capacity does not determine how many valves may run simultaneously—follow the controller’s electrical and operating limits.

Frequently Asked Questions

Which controllers accept ESPLXMSM12?

Rain Bird lists ESP-LXME, ESP-LXMEF and ESP-LX Basic compatibility, and identifies ESPLXMSM12 as the 12-station module for LXME2 and LXME2 PRO.

Can it be added without turning off the controller?

Rain Bird describes the station module as hot-swappable. Follow the installation instructions for your controller and complete the module configuration and wiring checks.

Can I mix the screw-terminal and older swing-arm modules?

Rain Bird’s terminal-block bulletin states that the old and new station modules are interchangeable and can operate together in the same controller.

Does one module make the controller a 48-station model?

No. One module provides 12 station outputs. Total capacity depends on the controller and installed modules; LXME2/PRO uses four 12-station modules to reach 48 stations.
