Mansfield 4115-3106 Barrett SmartHeight Elongated Two-Piece Toilet – 1.28 GPF

Mansfield 4115-3106 Barrett SmartHeight Elongated Two-Piece Toilet – 1.28 GPF

Brand: Mansfield Plumbing | SKU: 4115-3106

Product Overview

The Mansfield 4115-3106 Barrett combines an elongated bowl, SmartHeight seating height and a 1.28 GPF high-efficiency flush in a two-piece toilet designed for a standard 12-inch rough-in. The taller SmartHeight format can make sitting down and standing up easier for many users, while the elongated bowl provides additional front-to-back seating room compared with a round-front design.

A concealed trapway gives the base a cleaner appearance and reduces exposed contours around the discharge path, making routine exterior cleaning easier. Mansfield specifies its MagnaFlush flushing system with a 3-inch flush valve for this configuration, along with a 2-1/8-inch trap diameter and 800-gram MaP rating. The toilet is WaterSense certified and ADA compliant when installed according to applicable requirements. A toilet seat and water-supply line are not included.

Key Features

• Elongated SmartHeight bowl
• 1.28 GPF high-efficiency flush
• Concealed trapway for a cleaner profile
• MagnaFlush system with 3 in. flush valve
• 12 in. rough-in
• WaterSense certified
• ADA-compliant configuration when properly installed

Common Uses

Bathroom remodels and replacements where an elongated, chair-height toilet with reduced water use and a concealed trapway is preferred.

Technical Specifications

• Configuration: Two-piece toilet
• Bowl: Elongated SmartHeight
• Water use: 1.28 GPF / 4.86 LPF
• Water surface: 8-1/4 x 10-3/8 in.
• Trap diameter: 2-1/8 in.
• Trap seal: 2-1/4 in.
• Rough-in: 12 in.
• MaP rating: 800 grams

Compatibility & Installation Notes

Measure for a 12-inch rough-in before ordering. Toilet seat and water-supply line are not included. ADA compliance depends on the completed installation meeting applicable requirements.

Frequently Asked Questions

Does the 4115-3106 include a toilet seat?

No. The seat is sold separately.

What does SmartHeight mean?

SmartHeight identifies Mansfield’s taller seating configuration, intended to provide a more comfortable sitting and standing height for many users.

How much water does it use?

The Barrett 4115-3106 uses 1.28 gallons per flush and is WaterSense certified.

What rough-in does it require?

Mansfield specifies a 12-inch rough-in.
