Liberty Pumps PRG102M ProVore Grinder Pump, 1 HP, 230 V, Manual
Brand: Liberty Pumps | Model: PRG102M
Product Overview
The PRG102M is a 1 HP ProVore grinder pump for residential sewage applications. Its V-Slice cutter handles difficult waste before pumping through a 2 in. discharge line. This 230 V model is a manual model for use with a separately selected control method.
Key Features
- V-Slice cutter with hardened stainless steel components.
- Cast iron motor housing and volute with oil-filled, thermally protected motor.
- Manual configuration without an integral float switch.
Common Uses
Residential sewage grinder installations where a 2 in. discharge and the specified 230 V supply fit the system design.
Technical Specifications
- Power: 1 HP, 230 V, single phase, 60 Hz
- Current: 6 A
- Discharge: 2 in. NPT
- Standard cord: 10 ft
- Operation: manual; no integral float
- Weight: 57 lb
Dimensions
Manufacturer dimensional drawing shows an overall height of 17.6 in.; check the drawing for installation clearances.
Compatibility & Installation Notes
Confirm power, basin space, discharge piping, controls, and actual head requirements with the system designer. Liberty Pumps advises consulting the factory about the application and head specifications before replacing an LE40 or LE50 pump.
FAQs
Does this model include automatic switching? No. This manual model needs an appropriate external control arrangement.
What cord comes standard? The manufacturer lists a 10 ft cord for this exact model.
Why Buy from Big Frog Supply
Choose the exact PRG102M for 230 V power and manual control, with the manufacturer specifications available to confirm your installation.
Reviews
There are no reviews yet.
