K-Rain 6605 6-Outlet 6000 Series Valve for 5-Zone Operation

K-Rain 6605 6-Outlet 6000 Series Valve for 5-Zone Operation

Brand: K-Rain | SKU: 6605

Product Overview

The K-Rain 6605 is a 6-outlet 6000 Series indexing valve configured for 5-zone operation. The installed cam advances through 5 selected outlets and leaves 1 physical outlet outside the operating sequence as the upstream pump or control valve shuts off and restarts.

This higher-capacity six-outlet valve supports larger piping and higher hydraulic demand than the 4000 Series while using a five-zone cam that leaves one physical outlet outside the sequence.

Before ordering, confirm the outlet count, zone sequence, inlet and outlet sizes, available flow, operating pressure, and whether the installation requires separate backflow protection. Indexing valves depend on a complete interruption of water flow between cycles so the internal stem-and-disc assembly can reset and advance.

Key Features

• 6-outlet body with 5-zone operating cam
• Water-operated indexing between downstream zones
• 1½-inch female NPT inlet
• Six 1½-inch slip outlets
• 15- to 150-GPM flow range
• 25- to 150-PSI operating range
• Die-cast metal upper housing with high-strength ABS polymer outlet body
• Built-in atmospheric vacuum breaker
• Current manufacturer warranty listed as seven years

Common Uses

• Five-zone pump-fed irrigation
• High-flow commercial landscape distribution
• Replacing a compatible 6605 valve
• Approved five-zone wastewater or effluent systems

Technical Specifications

• Series: 6000 Series
• Valve configuration: 6 physical outlets / 5 operating zones
• Inlet connection: 1½-inch female NPT inlet
• Outlet connection: Six 1½-inch slip outlets
• Flow range: 15- to 150-GPM flow range
• Pressure range: 25- to 150-PSI operating range
• Body construction: Die-cast metal upper housing with high-strength ABS polymer outlet body

Compatibility & Installation Notes

Identify the five active outlets before piping. Install vertically, use approved thread sealant and solvent cement, and allow water flow to stop completely between cycles. Confirm the supply, valve, and piping can deliver the selected zone flow at the required dynamic pressure.

Frequently Asked Questions

Why are there six outlets for five zones?
The five-zone cam leaves one physical outlet outside the operating rotation.

Can the valve be changed to six zones?
Yes. Install the compatible six-zone cam and connect the unused outlet.

Are the outlets 1 inch like some 4000 Series valves?
No. The 6000 Series outlets are sized for 1½-inch PVC connections.
