Brand: Intermatic | Manufacturer Part Number: WP1050 | Big Frog Supply SKU: WP1050
Product Overview
The Intermatic WP1050 is a clear, deep double-gang in-use weatherproof cover for compatible GFCI and round receptacle applications. Its 4.75-inch depth provides additional clearance for larger cord-and-plug connections while the clear UV-stabilized polycarbonate construction keeps the device area visible without opening the cover. The included inserts can be rotated to accommodate approved horizontal or vertical single-gang device arrangements within the double-gang cover installation.
Key Features
- Clear double-gang vertical in-use cover
- Deep 4.75-inch profile for added connection clearance
- UV-stabilized polycarbonate cover, base, and inserts
- Outdoor Type 3R plastic enclosure classification
- WP102 GFCI and WP107 round-receptacle inserts included
- Rotatable inserts for horizontal or vertical device orientation
- 3 mm neoprene gasket
Common Uses
- Outdoor GFCI receptacle protection
- Round receptacle and cord connections
- Deeper in-use plug configurations
- Residential and light-commercial outdoor electrical boxes
Technical Specifications
- Gang count: Double
- Hinge direction: Vertical
- Color: Clear
- Material: UV-stabilized polycarbonate
- Enclosure type: Outdoor Type 3R plastic
- Extra-duty rated: No
- Maximum accepted cord: One 10 AWG or two 14 AWG cords
- Included inserts: WP102 and WP107
Dimensions
- Depth: 4.75 inches
- Height: 6 inches
- Width: 5 inches
Installation Notes
Install only on a compatible electrical box and approved receptacle arrangement with power disconnected. Select and orient the correct insert, use the included gasket and approved hardware, and follow the manufacturer instructions. Proper mounting and sealing are required for weather-resistant performance.
Frequently Asked Questions
Which inserts come with the WP1050?
It includes the WP102 GFCI insert and WP107 round-receptacle insert.
Is the WP1050 extra-duty rated?
No. It is a Type 3R plastic in-use cover but is not identified as extra-duty.
How deep is the cover?
The cover depth is 4.75 inches.
Why Buy This Product from Big Frog Supply?
The WP1050 is the deeper clear option for customers who need additional plug clearance and compatibility with GFCI or round receptacles. Big Frog Supply clearly identifies the included inserts, cord limits, and 4.75-inch depth so it can be compared accurately with shallower WP models.
