Product Overview
The DIG 06-620 converts a compatible 1/2 in. sprinkler riser into a six-outlet adjustable drip distribution point. Each outlet can be adjusted independently from shutoff to 20 GPH for routing water through compatible 1/4 in. micro tubing or dripline.
Key Features:
- Six independently adjustable outlets
- 0-20 GPH flow range per outlet
- Female pipe-thread inlet for a compatible sprinkler riser
- Swiveling 1/4 in. barbed mini valves
- Accepts compatible 1/4 in. distribution tubing or dripline
- EPDM diaphragm and high-impact plastic components
Common Uses:
- Converting an existing sprinkler riser to drip irrigation
- Distributing water to multiple containers or plants
- Creating individually adjustable micro-irrigation branches
Technical Specifications:
- Outlets: 6
- Flow Range: 0-20 GPH per outlet
- Operating Pressure: 15-50 PSI
- Maximum Water Temperature: 122°F
- Outlet Size: 1/4 in. barbed mini valve
- Compatible Tubing ID: 0.150-0.170 in.
- Filter Requirement: Minimum 40 mesh
Installation and Use Notes:
Thread the manifold onto a compatible 1/2 in. riser, connect the required tubing, and adjust each outlet to suit its planting area. It may be installed above grade or protected below grade in a suitable emitter box.
FAQ:
Can each outlet be adjusted separately?
Yes. Each outlet adjusts from shutoff to 20 GPH.
What tubing connects to the outlets?
Use compatible 1/4 in. distribution tubing or 1/4 in. dripline.
